Part 12009543 Dishwasher Programmed Power Control Module
Purpose
Manages electrical power routing and cycle programming.
Details
The 12009543 Programmed Power Control Module acts as the primary circuit hub for the dishwasher. It receives user inputs from the selector panel and systematically routes operating voltage to critical sub-systems, including the circulation wash pump, drain pump, thermal heating elements, and water inlet valve. Due to its position handling direct current, the internal circuitry is vulnerable to damage from household power surges, voltage drops, or cumulative thermal degradation. When this main board fails, common operational symptoms include a dishwasher that will not turn on, an unresponsive control interface, failure to advance through cycle stages, or specific fault codes such as an E02 heating error.
Included Items
Pre-programmed electronic power module board assembly. Required tools: Screwdrivers / Torx drivers.
Compatible Brands
Bosch, Thermador, Gaggenau
Replaces
4581398, AP5984999, PS11725049
Highlights
- Genuine OEM part
- Application: Dishwasher electrical and command systems
- Purpose: Directly coordinates timing and power delivery across all mechanical cycle functions
- Dimensions: 12.60 x 7.13 x 3.50 inches
- Installation difficulty: Hard
Safety Note
Always disconnect power before servicing. Follow model-specific diagrams and safety instructions for installation.
